Printer Storage Cabinet – Cara Collection

Today I’m sharing the plans for the Cara Collection printer storage cabinet.  You could add adjustable shelves or drawers to use this triple wide cabinet for other storage.  Alter any dimensions you need to in order to fit your needs.


Printer storage cabinet

Materials:

  • 1 Sheet of 3/4″ Cabient Grade Plywood or MDF cut as shown
  • 1 sheet of 1/4″ plywood, hardboard or beadboard for backs
  • 1 3/4″ wood screws
  • wood glue
  • 3/4″-1 1/2″ staples or #6 wood screws
  • 1×2 poplar for faceframes
  • 2  1/2″ – 3″ plywood or hardwood scraps for cleats
cut list for 19 and 24 base cabs - cara

1.  Build two 20 1/2″ wide cabinets

  • Use wood glue and 1 3/4″ SPAX screws to assemble 2 cabinets to the specifications shown below.  Adjust the height of the bottom of the cabinets to work with your specific baseboard as talked about in the post for the Bookshelf Base Cabinets.
  • Screw directly into the side of the cabinet to secure the cleats and bottom shelf to the sides.  Make sure you sink them just below the surface of the wood.  The screws will be hidden by the “legs”.
19x 19 base cabs - cara~

–  Square up and attach back with staples or wood screws.

back for 19 base cab - cara

2.  Build one 25 1/2″ wide cabinet

  • Same instructions as in other cabinets
24 base cab - cara

–  Square up and attach back with staples or wood screws.

back for 24 base cab - cara



3.  Attach all three cabinets together

  • Two 20 1/2″ cabinets flank the wider cabinet.
  • Use same method to secure cabinet to each other as given in the Upper Bookshelf plan

4.  Build and attach face frame

  • Use pocket hole screws to build face frame as dimensioned below after making sure it will fit your joined cabinets.  You want the outside stiles of the face frame to be flush with the cabinet sides with no overhand this time.  The cabinet sides will be hidden by the legs.  (Plans provided in the next post.)
  • Use wood glue and finish  nails or pocket hole screws to attach face frame to joined cabinet trio.
  • Add a cleat that is the same thickness as your face frame material to the bottom of the cabinets to ensure the baseboard sits flush when it is attached.
  • You may choose to add an extra rail if you want to add the 4″ drawers for storage.
Cara Middle cab faceframe= cara



5.  Build drawers (optional)

  • These drawers should fit leaving 1/2″ clearance on each side for a drawer glide.  Make sure you check the actual cabinet opening for your cabinets as they are often not exactly what you planned on them being.  Adjust the drawer to be 1″ more narrow than the width of the cabinet opening.
  • Follow instructions in How to Build a Cabinet Drawer post.
  • Follow these instructions for help with Installing Cabinet Drawers



– Drawer for the outer 2 cabinets.

middle section, left side, 4 Drawers, 18 deep cab

– Drawer for center cabinet.

center cabinets, center drawer

6.  Build drawer fronts (if you built drawers)

  • These 4″ drawers are too short for rail and style fronts.  Cara just used a solid piece of MDF or Poplar for her drawer fronts.
  • Follow This tutorial for attaching drawer fronts to drawers.


There are 4 additional plans for the Cara Collection office furniture. Plus, you can read all of Cara’s project update posts.
