How to install a pocket door frame

I love using pocket doors as often as the situation allows because they don’t take up any floor space when open. The right situation being that the pocket door wall is long enough to accommodate twice the width of the door – because it has to slide into the wall.

How to install a pocket door frame ~ https://sawdustgirl.com

Prepare Rough Opening

I’m using a pocket door kit because it makes the process super easy.  You just have to frame the rough opening in your wall and then install the kit. (These kits can be found at big box stores as well as online. Shop around.)

How to install a pocket door frame ~ https://sawdustgirl.com

Obviously you’ll want to read YOUR instructions for the kit you purchase!  My kit called for a rough opening height to be the height of my door + 4 1/2″ with a minimum  height of 84 1/2″.  The width called for was the width of my door times two + 1″.

  • My door is 80″ so my opening height is 84 1/2″.
  • My door is 36″ wide so my opening width is 73″.
How to install a pocket door frame ~ https://sawdustgirl.com

Install Header

The next step is to put a nail or screw in the center of each side jamb (the studs on the side of the pocket door opening).  The placement of this nail (in my case) is determined by your finished floor height .

How to install a pocket door frame ~ https://sawdustgirl.com

Then the pocket door frame header will rest on these nails while you make sure everything is level.  Once you have determined that the header is level, secure each side with screws.  The wider part of the header goes over where the actual door opening will be.  You may have to trim your header.  If you do, a metal blade on a reciprocal saw works great.

How to install a pocket door frame ~ https://sawdustgirl.com

Install Split Jams

Now you have to secure the “split jambs” in place.  One set of split jambs will be butted up to the header nailer.  The other will be installed halfway between the first set and the side jamb.

How to install a pocket door frame ~ https://sawdustgirl.com

Draw a line

Either snap a chalk line or use a straight edge to draw a line on the floor even with the side jambs.

How to install a pocket door frame ~ https://sawdustgirl.com

Install Floor Plates

Slip the split jambs into the tabs of the floor plate, center the plate within the lines on the floor and mark the location of the screw holes.

How to install a pocket door frame ~ https://sawdustgirl.com

Now remove one of the jams and secure the plate to the floor. The instructions may not mention removing one of the jams while driving the screws -but in my experience it’s easier to just get one of those jams out of the way temporarily. The only reason you need them in place at this point is to get the plate properly lined up. If you mark the screw holes with the jams in place you don’t need them there while driving the screws.

How to install a pocket door frame ~ https://sawdustgirl.com

Level And Secure Split Jams

Note that only one end of the split jambs has a set of holes on the metal side. The end with the holes is the “top”. The holes are there so you can drive screws through them and into the header nailer.

Now that the floor plates are secured to the floor, slide both jams in place making sure the metal side is facing IN and the end with the holes is UP.

How to install a pocket door frame ~ https://sawdustgirl.com

Make sure the split jambs are level and secure them each with two screws.

How to install a pocket door frame ~ https://sawdustgirl.com

The necessary screws may or may not be supplied with your kit. Mine either didn’t come with them or I misplaced them so I grabbed a handful of drywall screws that were sitting right there – which was a mistake!  The drywall screw split my jamb.  I ran downstairs for a box of self drilling wood screws which I used for the rest of the holes.

How to install a pocket door frame ~ https://sawdustgirl.com

That’s the pocket door kit in a nutshell.  You can hang the door now or later using the hangers/wheels that come with the kit. There should also be a bumper that you attach the the inside jamb so your door doesn’t slam into that stud.

How to install a pocket door frame ~ https://sawdustgirl.com

It’s definitely easier to hang the door before you trim the doorway, but I like to install drywall, mud, sand, paint, etc. before hanging the door. You CAN remove pocket doors after the trim has been installed, it just requires a bit more finesse.
