Built in Storage Bench – the Malisa Collection

Today I’m sharing the bench plans from Malisa’s mudroom lockers? You can use my basic cabinet building tutorials for more help with the basics.

Built-in Bench Plans

Built in Bench Plans

Entryway bench plans

If you are building lockers between two walls like Malisa did you won’t need to worry about hiding your screws and can use Wood Screw method for building.  If your lockers will be stand alone with visible sides use either pocket screw’s or dado’s to build.

Materials:

  • 3/4″ plywood or MDF
  • 1 1/4″ pocket screws or 1 3/4″ wood screws
  • 1×2 poplar for faceframe
  • 1/4″ backing material:  beadboard, plywood or masonite

Step 1

  • Cut toe kick with jigsaw
Built in Bench Plans

Step 2

  • use 1 3/4″ wood screws to secure dividers to top and bottom
Built in Bench Plans without sides

Step 3

  • Attach sides with wood screws (or pocket screws if sides will be visible)
Built in Entryway Bench Plans

Step 4

  • Build supportive base and secure it to bench by screwing sides of base to sides of bench
Base for Built in Bench Plans

Step 5

  • Attach cleats inside cubbies flush with back with pocket screws
Built in Entryway Bench Plans

Step 6

  • Attach back with small finish nails or staples after squaring up.
Built in Bench Plans

Step 7

Built in Bench Plans

Step 8

Add a bench top of your choice.  You can have it flush with the face frame or extend by 1″ or so.  If you are doing overlay drawer fronts you’ll probably want to extend the top so it sticks out as far as the drawer fronts (at least).   You could use any of these countertop tutorials to build a top for your bench.

Built in Bench Plans

You Might ALso Like

3 Comments

  1. Do you have plans for the rest of the built in? Like the lockers and drawers? Thanks!!

  2. Thanks for sharing! Just found your blog. Love it! Was planning something like this for my entry way closet but will modify it to allow removal to access crawl space.

  3. Jamie gadoury says:

    do you think MDF is strong enough for a bench like this? I’m about to build a hall tree with a bench and was curious because MDF is so much cheaper then 3/4″ply. TIA!
